Product Description:
Automated 5 Part Differential Analyser
Product Features:
- Tri angle laser-based flow cytometry for WBC and differentials enumeration
- 34 reportable parameters including NLR, NRBC, and CWBC
- Electrical impedance method for RBC and Platelet enumeration
- Three reagents usage ensure cost-effectiveness
- 15 µl sample volume
- Throughput 60 samples/ hr
- 3 counting modes -Whole blood, Capillary and pre-dilute
- Large storage capacity of 100000 samples
- Bidirectional Interfacing
- Assured Quality with NABL compliance
- QR code scanner facilitates direct inputs of QC values
- Large coloured LCD touch screen of 10.4 inch
Product Applications: CBC + Diff Analysis
Analytical Modes:
Manual, Predilute, Capillary
Total Parameters:
32: WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PCT, PDW-CV, PDW-SD, P-LCR, P-LCC, Neu%, Lym%, Mon%, Eos%, Bas%, Neu#, Lym#, Mon#, Eos#, Bas#, ALY%*, LIC%*, ALY#*, LIC#*, NRBC%*, NRBC#*
Principle of measurement:
RBC/PLT/WBC: Electrical Impedance
DIFF: 3 Angle Laser Flow Cytometry
HGB: Cyanide Free Colorimetry
MCV: Measured
HCT: Calculated
Graphics:
3 Histograms (WBC/RBC/PLT).
4 Scatterplots (DIFF x3, BASO).
Sample Volume:
Whole blood : 15 µL
CBC Only : 11 µL
Pre-diluted : 20 µL
Capillary : 20 µL
Sample Volume:
Whole blood : 15 µL
CBC Only : 11 µL
Pre-diluted : 20 µL
Capillary : 20 µL
Linearity Range:
WBC (x 10^9/L): 0 – 300
RBC: (x 10^12/L) 0 – 8.50
Hb (g/dL):0 – 25.0
HCT (%): 0 – 67
PLT (x 10^9/L): 0 – 3000
Calibrator:
ELite H Cal (3mL)
Open Vial Stability at 2-8˚C: 7 Days
Tri-level Controls:
Elite H5 CON L, N, H (3mL)
Open Vial Stability at 2-8˚C: 7 Days
Throughput:
Up To 60 Tests/Hr
QC (L-J, X-BAR):
Yes
Data Storage:
50,000 Results with Graphs
Dimension (mm):
364 x 498 x 431
Weight (Kg):
26.5
Reagents:
Erba H560 Dil (20 L)
Erba H560 Lyse 1 (200mL)
Erba H560 Lyse 2 (500mL)
Elite H Clean (50mL)
Interfaces:
4 USB + 1 LAN Port
Operating Environment:
15-30˚C
Atmospheric Pressure
70kPa~106kPa
Power Requirement:
A.C.100-240V ; 50/60Hz; ≤200VA
*Research use only
