- High throughput and the maximum testing samples capacity can reach to 144; with changeable and flexible scheme (samples capacity are optional among 48,96,144).
- 3 Independent systems for different requirement of samples, which can be uploaded, run, analyzed simultaneously independently.
- Samples are in or out automatically and hot lid is warmed automatically.
- Wireless remote control and analysis in real-time.
- Carry positive detection rate analysis by itself. Laboratory pollution will activate the early warning.
- Equip with database and LIS connection.
- Reserve full-automatic PCR link function.
- Equip with temperature gradient function.
- Adopt long life LED, which guarantee the stability and reliability of the optical system.
- Unique humanized module design, which can conduct experiment with 18×8 connected pipe simultaneously.
- User can set report form, multicolor printing; analysis and print function can be set up.
- Powerful automatic gain and automatic background correction; the first to achieve that self-adapting reagent detection when the background is too low or too high and signal is too low or too high in domestic.
Sample Volume:
3x48x0.2ml centrifugal tube (10 – 100µ), adapt to 18×8 connected pipe.
Sensitivity:
As low as 1 copy.
Fluorescence Channel:
[F1~F2; F1~F4; F1~F6](Optional); F7~F8(Reserved)
Temperature Range:
30.0 – 99.9°C
Temperature Uniformity:
± 0.3°C9(@55°C)
Precision of Temperature Control:
± 0.1°C(@55°C)
Warming Rate (MAX):
≥4.5°C/s
Cooling Rate (MAX):
≥4.5°C/s
Hot Lid Temperature Range:
30~105°C
Fluorescence Intensity Test Repeatability:
CV≤3%
Sample Test Repeatability:
CV≤3%
Sample Linear:
Linear regression coefficient, r≥0.980
Fluorescent Linear:
Linear regression coefficient, r≥0.990
Instrument Communication Interface:
USB2.0
Operating System:
Windows XP Sp3/Vista/7/8
Input Power:
100~240V, 50/60Hz, 1500W
Dimension (mm):
586x526x780(LxWxH)
Net Weight (kg):
65(exclude computer)
